TP-Link EAP660 HD Omada AX3600 Wireless Dual Band Multi-Gigabit Ceiling Mount Access Point, 2402Mbps @ 5GHz POE+, SNMP, MU-MIMO, QoS, Mountable

TP-Link EAP660 HD AX3600 Wireless Dual Band Multi-Gigabit Ceiling Mount Access Point

• Ultra-Fast Wi-Fi 6 Speeds: Simultaneous 1148 Mbps on 2.4 GHz and 2402 Mbps on 5 GHz totals 3550 Mbps Wi-Fi speeds.†
• High-Density Connectivity: 4× increased capacity to connect more devices simultaneously.‡
• Integrated into Omada SDN: Zero-Touch Provisioning (ZTP)§, Centralised Cloud Management, and Intelligent Monitoring.
• Centralised Management: Cloud access and Omada app for ultra convenience and easy management.
• 2.5G Port: A 2.5 Gbps Ethernet port boosts total internet throughput.
• Seamless Roaming: Even video streams and voice calls are unaffected as users move between locations.△
• PoE+ Support: Supports Power over Ethernet (802.3at) for convenient deployment and installation.
• Secure Guest Network: Along with multiple authentication options (SMS/Facebook Wi-Fi/ Voucher, etc.) and abundant wireless security technologies.

HARDWARE FEATURES
Interface 1× 2.5 Gbps Ethernet Port (supports IEEE802.3at PoE)
Button Reset
Power Supply • 802.3at PoE
• 12 V DC
Power Consumption • EU: 18.5 W
• US: 21.5 W
Dimensions ( W x D x H ) 9.6 × 9.6 × 2.5 in (243 × 243 × 64 mm)
Antenna Type Internal Omni
• 2.4 GHz: 4× 4 dBi
• 5 GHz: 4× 5 dBi
Mounting Ceiling /Wall Mounting (Kits included)

WIRELESS FEATURES
Wireless Standards IEEE 802.11ax/ac/n/g/b/a
Frequency 2.4 GHz and 5 GHz
Signal Rate • 5 GHz: Up to 2402 Mbps
• 2.4 GHz: Up to 1148 Mbps

MANAGEMENT
Omada App Yes
Centralized Management • Omada Cloud-Based Controller
• Omada Hardware Controller (OC300)
• Omada Hardware Controller (OC200)
• Omada Software Controller
Cloud Access Yes (Through OC300, OC200, Omada Cloud-Based Controller, or Omada Software Controller)
Email Alerts Yes
LED ON/OFF Control Yes
Management MAC Access Control Yes
SNMP v1, v2c, v3

Package Contents • EAP660 HD
• Power Adapter
• Ceiling/Wall Mounting Kits
• Installation Guide

Why Choose This?

The TP-Link EAP660 HD Omada AX3600 Wireless Dual Band Multi-Gigabit Ceiling Mount Access Point delivers ultra-fast Wi-Fi 6 speeds up to 3550 Mbps (2402 Mbps on 5 GHz + 1148 Mbps on 2.4 GHz), perfect for high-density environments like offices, hotels, and stadiums supporting over 1000 concurrent clients. Its 2.5 Gbps Ethernet port and 802.3at PoE support ensure seamless multi-gigabit performance and easy installation without extra power adapters. Integrated with Omada SDN for centralized cloud management, it offers advanced features like seamless roaming, MU-MIMO, and OFDMA for superior efficiency and reliability.

Key Features

• Wi-Fi 6 AX3600 Speeds – Delivers blazing fast 3550 Mbps total throughput with 8 spatial streams and 1024-QAM for high-performance connectivity.
• High-Density Support – Handles 1000+ clients with 4x capacity boost via OFDMA and UL/DL MU-MIMO, ideal for crowded areas.
• 2.5 Gbps Ethernet Port – Boosts wired backhaul to multi-gigabit speeds, eliminating bottlenecks in high-speed networks.
• 802.3at PoE Powered – Simplifies deployment with single-cable power and data over Ethernet, no separate adapters needed.
• Omada SDN Integration – Enables centralized cloud management, zero-touch provisioning, seamless roaming (802.11k/v), and mesh networking.

Full Specifications

Official Resources: Tech Specs | Datasheet

Frequently Asked Questions

• Q: What Wi-Fi standard does the EAP660 HD support? It supports Wi-Fi 6 (802.11ax) with dual-band operation, delivering up to 2402 Mbps on 5 GHz and 1148 Mbps on 2.4 GHz.
• Q: Does it support PoE for installation? Yes, it supports 802.3at PoE+ for both power and data over a single Ethernet cable, simplifying deployment.
• Q: How many clients can it handle? Up to 1000+ concurrent clients, optimized for high-density environments with OFDMA and MU-MIMO.
• Q: Is it manageable via cloud? Yes, fully integrated with TP-Link Omada SDN for centralized cloud management, zero-touch provisioning, and seamless roaming.
• Q: What mounting options are available? Supports both ceiling and wall mounting with included kits for flexible installation.
