Ubiquiti Dream Machine Special Edition, Enterprise-grade, UniFi OS Console, All-In-One Unifi Solution, 8x GbE PoE RJ45 Ports, 3.5″ HDD Bay

Ubiquiti Dream Machine Special Edition

SKU: UDM-SE

Description: Enterprise-grade, rack-mount UniFi Cloud Gateway with full UniFi application support, 10 Gbps performance, and an integrated PoE switch.

Tech Specs: Click Here
Installation Guide: Click Here

Features:
•Includes full UniFi application suite for device management
•3.5+ Gbps routing
•Integrated 8-port PoE/PoE+ switch
•(1) 10G SFP+, (8) GbE RJ45 LAN ports including (2) PoE+, and (6) PoE
•(1) 10G SFP+, (1) 2.5 GbE RJ45 WAN ports
•1.3″ touchscreen
•128 GB SSD 3.5″ HDD bay

Why Choose This?

The Ubiquiti Dream Machine Special Edition (UDM-SE) is an enterprise-grade all-in-one UniFi OS console that combines a high-performance security gateway, integrated PoE switch, and NVR for seamless network management and surveillance. With 3.5 Gbps IPS routing, support for 100+ UniFi devices and 1,000+ clients, dual high-speed WAN options, and a 180W PoE budget, it empowers businesses to scale efficiently while protecting assets with advanced security features like intrusion prevention and zone-based firewalls.

Key Features

• 10G Cloud Gateway with 3.5 Gbps IDS/IPS throughput – Delivers enterprise-level routing and threat protection for high-demand networks.
• Integrated 8-port GbE PoE switch (6x PoE, 2x PoE+) with 180W budget – Powers UniFi devices like access points and cameras directly, reducing cabling needs.
• Dual WAN (10G SFP+ and 2.5 GbE RJ45) – Ensures redundancy and high-speed internet failover for reliable connectivity.
• UniFi OS with full app suite (Network, Protect, Access, Talk, Connect) – Centralized management of devices, cameras (up to 14x 2K), and VoIP from one interface.
• 128 GB SSD + 3.5″ HDD bay for NVR – Enables efficient video storage and fast OS performance for UniFi Protect surveillance.

Full Specifications

Official Resources: Tech Specs | Datasheet

Frequently Asked Questions

• Q: What type of HDD is compatible with the 3.5″ bay? 1TB+ CMR 3.5″ surveillance-grade HDD (e.g., WD Purple), 7200 RPM recommended; no maximum capacity limit.
• Q: How many cameras can the UDM-SE support? Up to 24 HD, 14 2K, or 8 4K cameras via UniFi Protect with HDD installed.
• Q: What is the PoE configuration? 6 ports PoE (15.4W max), 2 ports PoE+ (30W max), total 180W budget.
• Q: Does it support redundancy? Yes, via Shadow Mode (VRRP) for failover and USP-RPS DC input for power backup.
• Q: What WAN options are available? Dual default WAN: 1x 10G SFP+ and 1x 2.5 GbE RJ45; configurable up to 8 WAN ports.
