Ubiquiti Rocket 2AC Prism 2GHz Lite airMAX ac BaseStation, 150+ Mbps throughput, Integrated GPS sync,50+ Client Capacity, Dedicated Spectral Analysis
$397.46 inc GST
Manufacturer: Ubiquiti
Availability: BRS:2 ADL:2 SYD:1 MEL:4 WA:1
10 in stock
Ubiquiti Rocket 2AC Prism 2GHz Lite airMAX ac BaseStation
SKU: R2AC-PRISM
Tech Specs: Click Here
Description:
Full-band 2.4 GHz Point-to-Point (PtP) and Point-to-MultiPoint (PtMP) basestation. Provides up to 330+ Mbps data throughput.
Features:
•2.4 GHz airPrism active RF filtering technology
•150+ Mbps throughput
•50+ client capacity
•Dedicated spectral analysis radio
•Integrated GPS sync
Why Choose This?
The Ubiquiti Rocket 2AC Prism (R2AC-PRISM) is a high-performance 2.4 GHz airMAX ac base station designed for demanding PtP and PtMP deployments, delivering up to 330+ Mbps real TCP/IP throughput even in high-density environments. Its revolutionary airPrism active RF filtering eliminates up to 30+ dB of interference, while integrated GPS sync and dedicated spectral analysis via airView ensure optimal performance and scalability for 50+ clients. Perfect for ISPs and enterprises needing reliable, long-range wireless connectivity with advanced spectrum management.
Key Features
- airMAX ac Technology – Delivers up to 330+ Mbps throughput with improved latency, noise immunity, and scalability over standard Wi-Fi.
- airPrism Active RF Filtering – Removes 30+ dB of adjacent channel interference, enabling efficient AP co-location in dense deployments.
- Integrated GPS Sync – Provides precise timing synchronization (airOS v8.5+), boosting network throughput by up to 90% in carrier-class setups.
- Dedicated Spectral Analysis (airView) – Real-time spectrum monitoring with waveform, waterfall, and noise views without disrupting service.
- 50+ Client Capacity – Handles high-density PtMP networks with intelligent QoS, traffic shaping, and 256QAM modulation support.
Full Specifications
| Category | Details |
|---|---|
| Model | R2AC-PRISM |
| Dimensions | 88 x 40 x 230 mm (3.47 x 1.58 x 9.06″) |
| Weight | 400-440 g (14.1-15.52 oz) |
| Enclosure | Die-Cast Aluminum with White Powder Coating |
| Networking Interface | (1) 10/100/1000 GbE RJ45 Port |
| RF Connectors | (2) RP-SMA (Waterproof), (1) GPS (Waterproof) |
| LEDs | Power, LAN, GPS, (4) Signal Strength (Software-Adjustable) |
| Max. Power Consumption | 8.5-9.5W |
| Power Supply | 24V, 0.5A Gigabit PoE Adapter (Included) |
| Power Method | Passive PoE (Pairs 4,5+; 7,8 Return) |
| Supported Voltage Range | 18-27V DC |
| Processor | Atheros MIPS 74Kc, 720 MHz |
| Memory | 128 MB DDR2 SDRAM, 16 MB NOR Flash |
| Operating Frequency (MHz) | Worldwide: 2412-2472; US: 2412-2462 |
| Management Radio (MHz) | Worldwide: 5150-5250; US: 5725-5850 |
| Channel Sizes | 10/20/40 MHz |
| Max. TX Output Power | 27 dBm |
| Throughput | Up to 330+ Mbps (40 MHz channel) |
| Operating Temperature | -40 to 80°C (-40 to 176°F) |
| Operating Humidity | 5 to 95% Noncondensing |
| ESD/EMP Protection | ±24 kV Contact/Air (Ethernet) |
| Certifications | CE, FCC, IC, RoHS, NDAA Compliant |
| Operating Modes | Access Point, Station, PtP/PtMP |
| Security | WPA2 AES |
Official Resources: Tech Specs | Datasheet
Frequently Asked Questions
- Q: What is the maximum throughput of the R2AC-PRISM? Up to 330+ Mbps real TCP/IP throughput on a 40 MHz channel, thanks to airMAX ac and 256QAM modulation.
- Q: Does it support GPS synchronization? Yes, integrated GPS sync is available with airOS firmware v8.5.0 and newer for precise timing in multi-AP deployments.
- Q: What spectral analysis features does it offer? Dedicated airView spectrum analyzer provides real-time waveform, waterfall, and noise views without interrupting the wireless link.
- Q: How many clients can it support? Designed for 50+ client capacity in PtMP setups with intelligent QoS and traffic shaping for high-density use.
- Q: Is it suitable for outdoor high-density environments? Yes, airPrism technology filters 30+ dB of interference, enabling co-location of multiple APs in challenging 2.4 GHz spectrum.
| Weight | 0.98 kg |
|---|---|
| Dimensions | 122 × 280 × 90 mm |
| Product Create Date | 14/03/2017 |
| Web Link | Visit Manufacturer Page → |
|---|---|
| Manufacturer | Ubiquiti |
| Warranty | 12 |
| Manufacturer SKU | R2AC-PRISM |
| Opt Accessory | NHU-EXTWAR-UBNT-2YR, NHU-EXTWAR-UBNT-3YR, NHU-POE-24-24WG, NHU-EXTWAR-UBNT-5YR |
