Ubiquiti Next-generation UniFi Gateway Pro10G multi-WAN independent gateway with UniFi Power Backup support designed to protect large-scale networks.
$891.31 inc GST
Manufacturer: Ubiquiti
Availability: BRS:0 ADL:0 SYD:0 MEL:1 WA:0
1 in stock
Ubiquiti Gateway Professional
SKU: UXG-Pro
Description:Dual-WAN security gateway designed to protect medium to large-sized networks with enterprise-class firewall configuration and threat management features.
Tech Specs: Click Here
Installation Guide: Click Here
Features:
•(1) 10G SFP+ and (1) GbE WAN port
•(1) 10G SFP+ and (1) GbE LAN port
•DC power backup-ready
•1.7 GHz quad-core processor
•(2) WAN ports (GbE RJ45 and 10G SFP+) with failover support
•(2) LAN ports (GbE RJ45 and 10G SFP+)
•Enterprise-class DPI, IPS/IDS, and layered firewall configuration
•Power redundancy when connected to the UniFi SmartPower RPS (sold separately)
•SmartPower outlet (200~240VAC/1.25A) for an external modem
•1U-sized, rack-mountable device
•Managed with the UniFi Network application: Version 5.14.11 and later
Why Choose This?
The Ubiquiti UXG-Pro is a powerful 10G multi-WAN independent gateway designed to safeguard large-scale networks with enterprise-class security and high-performance routing. It delivers over 3.5 Gbps throughput with IDS/IPS enabled, supports UniFi Power Backup for redundancy, and offers versatile 10G SFP+ and GbE ports for demanding environments. Ideal for rackmount deployments, it ensures reliable connectivity, advanced threat protection, and seamless integration with UniFi Network management.
Key Features
- 10G Multi-WAN Support – Enables load balancing and failover across up to 3 WAN ports for uninterrupted connectivity.
- 3.5+ Gbps IDS/IPS Throughput – Provides high-speed intrusion prevention and deep packet inspection to secure large networks.
- UniFi Power Backup Ready – Supports RPS DC input for power redundancy, minimizing downtime.
- Quad-Core Processor & 2GB RAM – Delivers robust performance for routing, VPN, and security services.
- License-Free SD-WAN & VPN – Offers Site Magic, WireGuard, OpenVPN, and IPsec for flexible remote access and site connectivity.
Full Specifications
| Category | Details |
|---|---|
| Dimensions | 442.4 x 43.7 x 285.6 mm (17.4 x 1.7 x 11.2″) |
| Weight | 3.42 kg (7.54 lb) |
| Form Factor | Rackmount (1U) |
| Enclosure Material | Front panel: Aluminum CNC; Top cover/base: SGCC steel |
| Processor | Quad-core ARM Cortex-A57 at 1.7 GHz |
| System Memory | 2 GB DDR4 |
| LCM Display | 1.3″ touchscreen |
| WAN Ports | (1) 10G SFP+ (10G/1G), (1) 1 GbE RJ45; Max. 3 WAN ports |
| LAN Ports | (1) 10G SFP+ (10G/1G), (1) 1 GbE RJ45 |
| IDS/IPS Throughput | 3.5 Gbps |
| Security Features | Stateful Firewall, Application-Aware Layer 7 Firewall, DPI, IPS/IDS, Zone-Based Filtering, Content Filtering, Ad Blocking |
| VPN Server | Teleport, WireGuard, OpenVPN, L2TP |
| VPN Client | OpenVPN, WireGuard |
| Networking | Multi-WAN Load Balancing, Dynamic Routing (OSPF), Advanced QoS, mDNS, Advanced NAT |
| Power Method (US) | (1) Universal AC input (125V AC, 2.7A Max, 60 Hz), (1) RPS DC input (11.5V DC, 2.87A) |
| Max. Power Consumption | 30W |
| Power Supply | AC/DC, internal, 50W |
| Supported Voltage Range | 100–240V AC |
| Operating Temperature | -10 to 40°C (14 to 104°F) |
| Operating Humidity | 5 to 95% non-condensing |
| Certifications | CE, FCC, IC |
Official Resources: Tech Specs | Datasheet
Frequently Asked Questions
- Q: What is the difference between UXG-Pro and UDM-Pro? UXG-Pro is a dedicated gateway without built-in controller or storage, using less RAM but equivalent performance; pair it with a separate Cloud Key or self-hosted UniFi Network server, unlike the all-in-one UDM-Pro.
- Q: Does the UXG-Pro support power redundancy? Yes, it is UniFi Power Backup ready with RPS DC input alongside AC power for failover protection.
- Q: What management options are available? Managed by Cloud Key, Official UniFi Hosting, or UniFi Network Server (version 8.3.32+ required).
- Q: Can a UDM-Pro manage the UXG-Pro? No, UXG-Pro requires a separate UniFi Network controller; it cannot be adopted by UDM devices.
- Q: What VPN protocols does it support? VPN Server: Teleport, WireGuard, OpenVPN, L2TP; VPN Client: OpenVPN, WireGuard; plus license-free SD-WAN and Site Magic.
| Weight | 4.74 kg |
|---|---|
| Dimensions | 520 × 120 × 410 mm |
| Product Create Date | 19/04/2022 |
| Web Link | Visit Manufacturer Page → |
|---|---|
| Manufacturer | Ubiquiti |
| Warranty | 12 |
| Manufacturer SKU | UXG-Pro |
| Opt Accessory | NHU-UCK-G2-PLUS, NHU-CK-ENTERPRISE, NHU-UMR-INDUSTRIAL, NHU-UICARE-UXG-PRO-D |
